SW-10

SW-10 water level sensor

SW series water level sensor is a component designed for checking water level. According to the water level, the product sends oscillation frequency to the appliance’s control board. It depends on the pressure, magnetic field, and electric signal to realize the function.


Specification

Model

SW-10

Rated voltage

DC5V±0.1V





Frequency / Water level

21.850 kHz)

290±30mm

24.432 kHz)

95±8mm

24.716kHz)

75±4mm

25.002 kHz)

55±5mm

 Initial frequency

25.529-25.931 kHz)

0mm

Insulation resistance

Insulation resistance between live part and uncharged part ≥100MΩ




Environmental test


High temperature: put the product in(60±2)℃ for 168h, then back to normal temperature for 2h. After that, water level change of each gear is within ±15mm

Low temperature: put the product in (-20℃±2℃)for 168h, then back to normal temperature for 2h. After that, water level change of each gear is within ±10mm


Humidity resistance: put the product in (40℃±2℃, RH90%~95%)for 168h, then dry all water from the product, back to normal temperature for 2h. After that, water level change of each gear is within ±15mm

Durability test

With rated voltage, alternatively test the highest water level and lowest water level, frequency 20 cycles/min, total 50,000 cycles.

RoHS

Conform to RoHS 2011/65/EU



WORKING CONDITONS



Working temperature: -10℃,+50℃

Max altitude: 2500M

Max humidity: RH95% (+25℃)

Does not contain flammable, explosive and corrosive gas or steam

No significant shaking or severe shock and vibration




Diagram


Curve

Dimension
